S11-M.RL and S13-M.RL stereoscopic triangle coiled iron core transformers
Instead of the traditional plane structure, S11-M.RL and S13-M.RL stereoscopic triangle coiled iron core transformers adopts a three-phase symmetrical vertical structure. Three phases of iron core circuits of the product are completely symmetrical, which significantly reduces the magnetic reluctance as well as the excitation current and the no-load loss. This is an energy-saving transformer that uses traditional materials but has a lower running noise level and more compact structure. The excellent performance of such products in energy conservation, consumption reduction, material saving and environment protection totally conforms to China's energy saving policy.
Executive standards
1. GB1094.1-2013 Power Transformer
2. GB/T6451-2015 Technical Parameters and Requirements of Oil-immersed Power Transformer
3. JB/T10088-2004 Sound Level of 6kV~500kV Power Transformer
Product characteristics
1. Electric and energy saving: no-load loss decreases by 40-50%, and the load loss decreases by 7-10%
2. Low line loss: no-load current decreases by more than 90%
3. Ultra-silence: noise level decreases by 10-15dB
4. No interference: flux leakage decreases by more than 50%
5. Raw material saving: the cost of iron and copper decreases by 20-30%
6. Significant economic benefit: the power transformation cost within ten years decreases by 17.2% compared with the new s9
